ELEWIND 8mm Plastic 5 PIN terminal Latching momentary Round lock push button switch (PB81F-11D/G/12V , PB81F-11ZD/G/12V)

  1 2 3       8mm lock push button 8mm illuminated Latching push button switch Part number:PB081F-11ZD/G/12V Install diameter:8mm Switch rating: 2A/48V Shape: Round LED and Button color: Green,Blue,RED,Orange,White,Yellow Voltage: from 1.8V to 230V Function: Latching (1NO1NC) Terminal:5 PIN terminal Crust material: Plastic Temperature: - 25 to 55 Degree
