ELEWIND 22mm Ring illuminated square DPDT momentary latching Stainless steel push button switch (PM222S-11E/G/12V/S )

1

Part number:PM222S-11E/G/12V/S

Install diameter:22mm

Switch rating: 3A/250VAC

Shape: square head  ,

Function: Momentary or latching (1NO1NC)

Led type: Ring illuminated

Color: Green,Red,Yellow,Blue,White,Orange

Voltage: 12V

Terminal: Pin terminal

Crust material: stainless steel

IP rating: IP65

Temperature: - 40 to 75 Degree
