16mm Momentary push button switch with connect(PM162H-11E/R/12V/S,CE,ROHS)

1   Part number: PM162H-11E/R/12V/S/IP65 with connector   Install diameter:16mm Switch rating: 3A/250VAC Shape:High Flat head Function: Momentary (1NO1NC) Led type: Ring illuminated Color: Red(Other color can be choose:Red,Yellow,Green,White,Orange) Voltage: 12V (Other voltage can be make to order: 2.8V to 250V) Terminal: 5 Pin terminal IP Rating: IP40 / IP67  can be customized Crust material: Stainless steel crust Temperature: - 40 to 75 Degree
